Mini Size White Color Automatic Shopping Mall 2D Barcode Image
Reader
Product Features
◆ Desktop design for shop and store application.
◆ Excellent performance with low power consumption.
◆ High quality material insurance with 2 years warranty.
◆ Withstand 1.5m free drop, IP54 waterproof and dustproof standard.
◆ High sensitive scan engine, automatic reading all kinds of 1D and
2D barcodes.
◆ 640x480 pixels resolution, minimum 4 mil precision.
◆ Firmware can be easily upgraded online to solve the software
problem.
◆ 2D CMOS imager can support reading 1D and 2D barcodes on the
screen.
Product Specifications
| Model Number | XL-2300 |
| Image Sensor | CMOS |
| Image Size | 640x480 |
| Light Source | White light,LED |
| Minimum Resolution | ≥4mil Precision |
| Scanning Angle | Roll:360°, Skew: ±40°, Pitch: ±300° Viewing angle:Horziontal:70°,Vertical:50° |
| Scan Mode | Sense |
| Interface | RS232,USB |
| Size | L × W × H:115mm ×98mm × 79mm |
| Weight | 185g |
| Indicator | Voice: adjust tovolume and tone |
| Voltage | 5 VDC±5% |
| Current(Working) | 108mA (typical value),114mA (Maximum value) |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | 5%-95%(RH) |
| Light Levels | 0-100,000Lux |
| Drop Test | 2m |
| Decoding Capability | 1D:EAN-13,EAN-8,UPC-A,UPC-E,ISSN, ISBN, Codabar, Code
128(FNC1/FNC2/ FNC3),Code 93, ITF-6, ITF-14,Interleaved 2 of 5,
Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar
(RSS-Expand, RSS-Limited, RSS-14),Code 39(Code 39 FULL ASCII), Code
11, MSI-Plessey, Plessey , etc.
2D:PDF417, Data Matrix, QR Code, Chinese sensible code,etc |
Certificate
Application
Delivery
RFQ
1. How about the quality?
Professional QC team and testing machine(Engine age testing,wire
bending machine,switch life testing,shock resistance testing). All the products pass CE, FCC, ROSH, etc.
2. Why so competitive?
With over 13 years experience,we're listed barcode scanner
manufacturer in China.We are the Top 3 barcode scanner brand in
China.So large quantity will reduce our raw material cost
directly.What's more,we have mature technology to save cost.
3. How to control the performance stable?
We take the flow line production in the whole processing.Every
product will test 5 times at least before it delivery.
4. Is OEM or ODM available?
Yes.We are the factory directly.We can make it as your requirement.
5. Why customer choose us?
ISO9001 factory with strictly quality control system.Prompt
after-sales service.
6. How about the factory?
We have more than 200 workers with advanced dust-free plant.We are
approved the new high-tech enterprise by the government.Owned many
technical and design patents in different professional fields.
